Specifiche (EN) - Weingarten PA 180 (ID: S89417)
| Type | Screw press |
| Manufacturer | Weingarten |
| Model | PA 180 |
| Nominal force | 315 ton |
| Max force | 630 ton |
| Screw diam | 180 mm |
| Table dimension | 620 x 700 mm |
| Slide dimension | 640 x 350 mm |
| Stroke of the slide | 200 — 380 mm |
| Shut height | 560 mm |
| Distance between the uprights | 710 mm |
| Weight | 12 ton |
